| Place of Origin: | CHINA |
|---|---|
| Certification: | ISO |
| Model Number: | NK-MRR |
| Minimum Order Quantity: | 1 cubic metre |
| Price: | depends on quantity |
| Packaging Details: | jumbo bag and pallet, one 20ft can load 20m3 |
| Delivery Time: | 15 days for one 20GP container |
| Payment Terms: | L/C, D/P, T/T, Western Union, paypal |
| Supply Ability: | 300m3 per month |
| Product Name: | Metal Raschig Ring | Material: | Stainless Steel |
|---|---|---|---|
| Diameter: | 25mm, 38mm, 50mm | Application: | Distillation Column |
| Classfication: | Tower Packing, Random Packing, Column Packing | ||
| Highlight: | Metal Raschig Ring 25mm,Metal Raschig Ring 38mm,Distillation Tower Packing Raschig Ring |
||
Distillation Tower Packing Metal Raschig Ring 25mm, 38mm, 50mm
Product description
Metal rasching ring is made of materials like carbon steel, stainless steel or Aluminum alloy, etc.
The product has features such as thin wall, heat resistant, high free volume, high capacity, low resistance, high separation efficiency and so on.
It is especially suitable for rectification towers under vacuum to treat thermosensitive, decomposable, polymerizable or cokable systems, so it is widely used in packing towers in petrochemical industry, chemical fertilizer industry and environmental protection, etc.
Technical data
| Size mm |
Bulk density kg/m3 |
Number per m3 |
Surface area m2/m3 |
Free volume % |
| 15×15×0.3 | 379 | 230000 | 350 | 95 |
| 25×25×0.4 | 318 | 51000 | 216 | 96 |
| 25×25×0.5 | 400 | 51000 | 220 | 95 |
| 35×35×0.8 | 430 | 19000 | 150 | 93 |
| 50×50×0.5 | 203 | 6500 | 106 | 97.4 |
| 50×50×0.7 | 285 | 6500 | 108 | 96.4 |
| 50×50×0.8 | 325 | 7000 | 109 | 95 |
| 76×76×0.8 | 212 | 1830 | 69 | 97.3 |
| 80×80×1.2 | 300 | 1600 | 65 | 96 |
| 90×90×1.0 | 236 | 1160 | 62 | 97 |
The above data is reference to material stainless steel (AISI304) in the material thickness shown.
Material available:
carbon steel, stainless steel including 304, 304L, 410,316, 316L.
Package info
| package | bags | loaded volumn | |
| 20GP container | jumbo bag | 20 | 20m3 |
| 40GP container | jumbo bag | 44 | 44m3 |
| 40HQ container | jumbo bag | 44 | 50m3 |
One jumbo bag can load 1-1.5m3 metal pall ring.
Product photo
Production and shipment
Other metal random packing products
Pall ring, Raschig ring, Super raschig ring, Cascade ring, Intalox saddle ring, IMTP packing, Conjugate ring, VSP ring, metal improved inner arc ring
