10A 13X Molecular Sieve For PSA Oxygen Generator zeolite molecular sieve chemical auxiliary agent

10A 13X Molecular Sieve For PSA Oxygen Generator zeolite molecular sieve chemical auxiliary agent
10A 13X Molecular Sieve For PSA Oxygen Generator zeolite molecular sieve chemical auxiliary agent
10A 13X Molecular Sieve For PSA Oxygen Generator zeolite molecular sieve chemical auxiliary agent 10A 13X Molecular Sieve For PSA Oxygen Generator zeolite molecular sieve chemical auxiliary agent 10A 13X Molecular Sieve For PSA Oxygen Generator zeolite molecular sieve chemical auxiliary agent 10A 13X Molecular Sieve For PSA Oxygen Generator zeolite molecular sieve chemical auxiliary agent
Basic Information
Place of Origin: china
Brand Name: NAIKE
Certification: ISO9001:2008
Model Number: NK-10a
Minimum Order Quantity: 100 kilogram
Price: $1.00 - $3.00/ kilogram
Packaging Details: Conventional packing
Delivery Time: 5-8work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 Ton/Tons per Month
Contact Now
Other Names: Catalyst, Desiccant MF: Na2O . Al2O3 SiO2 .H2O
Purity: 99% Usage: Coating Auxiliary Agents, Electronics Chemicals, Leather Auxiliary Agents, Paper Chemicals, Petroleum Additives, Water Treatment Chemicals
Shape: Pellet/sphere(bead) Bulk Density: ≥0.61g/ml
Water Absorption: ≥23.5% Ethylene Adsorption: <18%
Water Content: <1.5% Application: Catalyst, Drying Agents, Oxygen Generator, Air Purification
Highlight:

10A Molecular Sieve

,

Catalyst Molecular Sieve

,

PSA Oxygen Generator Molecular Sieve

10A 13X Molecular Sieve For PSA Oxygen Generator zeolite molecular sieve chemical auxiliary agent 0
Product Parameters
Zeolite molecular sieve 10a is the sodium form of the type X crystal and has a much larger pore opening than the type A crystals. It will adsorb molecules with a kinetic diameter of less than 10 Angstrom (1 nm) and exclude those larger.
It also has the highest theoretical capacity of the common adsorbents and very good mass transfer rates. It can remove impurities too large to fit into a type A crystal and is commonly used to separate nitrogen from oxygen.

product name
zeolite molecular sieve 10a
type
10a
brand
Naike
shape
pellet, sphere
diameter
1-2mm, 2-3mm, 2.5-5mm
classfication
Chemical Auxiliary Agent
color
as picture
package
carton box, iron drum
MOQ
100 kilograms
regenetion
yes
delivery
7 days
place of origin
jiangxi, China
price
FOB shenzhen
payment term
T/T, L/C, west union
application
catalyst, dring agents, desiccant, oxygen generator, hydrogen purificatioon,air seperation, CO2 remover
Typical Chemical Formula
Na2O . Al2O3 . (2.8±0.2) SiO2 . (6~7)H2O
SiO2 : Al2O3 ≈2.6-3.0


Application
1) Removal of CO2 and moisture from air (air pre-purification) and other gases.
2) Separation of enriched oxygen from air.
3) Removal of mercaptans and hydrogen sulphide from natural gas.
4) Removal of mercaptans and hydrpogen sulphide from hydrocarbon liquid streams (LPG, butane, propane etc.)
5) Catalyst protection, removal of oxygenates from hydrocarbons (olefin streams).
6) Removal of n-chained compositions from aromatics.
7) Production of bulk oxygen in PSA units .
8) Production of medical oxygen in small scale oxygen concentrators

Regeneration
zeolite molecular sieve 10a can be regenerated by either heating in the case of thermal swing processes; or by lowering the pressure in the case of pressure swing processes.
To remove moisture from a zeolite molecular sieve 10a, a temperature of 250-300°C is required. A properly regenerated zeolite molecular sieve 10a can give moisture dew points below -100°C, or mercaptan or CO2 levels below 2 ppmv.
The outlet concentrations on a pressure swing process will depend on the gas present, and on the conditions of the process

Size
Zeolite molecular sieve 10a is available in beads of 1-2 mm, (10x18 mesh) 2-3 mm, (8x12 mesh) , 2.5-5 mm, (4x8 mesh) and as powder, and in pellet 1.6, 3.2.

Attention
To avoid damp and pre-adsorption of organic before running, or must to be reactivated.
Pingxiang Naike Chemical Industry Equipment Packing Co., Ltd. (also known as NKCHEM), the top leading mass transfer product manufacturer of tower packing (column packing) and chemical ceramic. NKCHEM was established from the consortion of several existing factories with a long history.
Item
Unit
Technical data
Shape

Pellet
Sphere
Diameter
mm
1.5-1.7
3.0-3.3
1.7-2.5
3.0-5.0
Size ratio up to grade
%
≥98
≥98
≥96
≥96
Bulk density
g/ml
≥0.68
≥0.68
≥0.68
≥0.68
Wear ratio
%
≤0.10
≤0.20
≤0.10
≤0.10
Crushing strength
N
≥30/cm
≥45/cm
≥25/piece
≥65/piece
Static water adsorption
%
≥23.5
≥23.5
≥23.5
≥23.5
Static CO2 adsorption
%
≥18
≥18
≥18
≥18
Water content, as shipped
%
≤1.5
≤1.5
≤1.5
≤1.5
Details Images
10A 13X Molecular Sieve For PSA Oxygen Generator zeolite molecular sieve chemical auxiliary agent 1
10A 13X Molecular Sieve For PSA Oxygen Generator zeolite molecular sieve chemical auxiliary agent 2
10A 13X Molecular Sieve For PSA Oxygen Generator zeolite molecular sieve chemical auxiliary agent 3
10A 13X Molecular Sieve For PSA Oxygen Generator zeolite molecular sieve chemical auxiliary agent 4
10A 13X Molecular Sieve For PSA Oxygen Generator zeolite molecular sieve chemical auxiliary agent 5
10A 13X Molecular Sieve For PSA Oxygen Generator zeolite molecular sieve chemical auxiliary agent 6
10A 13X Molecular Sieve For PSA Oxygen Generator zeolite molecular sieve chemical auxiliary agent 7
Recommend Products
10A 13X Molecular Sieve For PSA Oxygen Generator zeolite molecular sieve chemical auxiliary agent 8
Company Profile
10A 13X Molecular Sieve For PSA Oxygen Generator zeolite molecular sieve chemical auxiliary agent 9
10A 13X Molecular Sieve For PSA Oxygen Generator zeolite molecular sieve chemical auxiliary agent 10
Exhibition
10A 13X Molecular Sieve For PSA Oxygen Generator zeolite molecular sieve chemical auxiliary agent 11
Cooperation Case
10A 13X Molecular Sieve For PSA Oxygen Generator zeolite molecular sieve chemical auxiliary agent 12
10A 13X Molecular Sieve For PSA Oxygen Generator zeolite molecular sieve chemical auxiliary agent 13
10A 13X Molecular Sieve For PSA Oxygen Generator zeolite molecular sieve chemical auxiliary agent 14
FAQ
Q1.Q:What are your main products?
A:Our main products are molecular sieve, ceramic ball, plastic,ceramic and metal tower packing, column internal parts, MBBR, etc...
Q2:Why to choose us?
A:Naike Chemical established since 1973. * Factory direct selling * High quality control * Promopt delivery and competitive price
Q3:What is the MOQ?
A:Our MOQ is 1 cubic meter or 1 ton. The price will be a little higher is the quantity is less tan 1 cubic meter or 1 ton.
Q4:What is the delivery time?
A:It will takes about 3-5 days. But the exact time is according to actual situation.
Q5:How do I pay for my purchase order?
A:T/T, L/C at sight, paypal, Alibaba Trade Assurance, etc...
Q6:Can I have my own customized product?
A:Yes, your customized requirements are welcome.
