5A Molecular Sieve In Psa Equipment Molecular Sieve For Oxygen Zeolite Zsm5 Catalyst

5A Molecular Sieve In Psa Equipment Molecular Sieve For Oxygen Zeolite Zsm5 Catalyst
5A Molecular Sieve In Psa Equipment Molecular Sieve For Oxygen Zeolite Zsm5 Catalyst
5A Molecular Sieve In Psa Equipment Molecular Sieve For Oxygen Zeolite Zsm5 Catalyst 5A Molecular Sieve In Psa Equipment Molecular Sieve For Oxygen Zeolite Zsm5 Catalyst 5A Molecular Sieve In Psa Equipment Molecular Sieve For Oxygen Zeolite Zsm5 Catalyst 5A Molecular Sieve In Psa Equipment Molecular Sieve For Oxygen Zeolite Zsm5 Catalyst
Basic Information
Place of Origin: China
Brand Name: NK CHEM
Certification: ISO9001:2000 & MSDS
Model Number: Oxygen Molecular Sieve
Minimum Order Quantity: 1 kilogram/kilograms(Min. order)
Price: $50.00 - $500.00/ kilogram
Packaging Details: 25kg carton drum, 150kg iron drum
Delivery Time: 15 days for one 20ft container
Payment Terms: L/C, D/P, T/T, Western Union, paypal
Supply Ability: 240 ton per month
Contact Now
Features: Oxygen Concentrator CAS No.: 63231-69-6
Other Names: Molecular Sieve Oxygen MF: Na2O. Al2O3. (2.8±0.2) SiO2. (6~7)H2O
EINECS No.: 13311-6 Purity: >92%
Type: Adsorbent Usage: Paper Chemicals, Petroleum Additives, Plastic Auxiliary Agents, Water Treatment Chemicals
Product: Molecular Sieve For Oxygen Concentrator Application: Air Separation
Static Water Adsorption (%): ≥27 Static CO2 Adsorption (%): ≥18.5
Bulk Density (g/ml): 0.65-0.70 Bulk Density(g/cm3): ≥0.62
Scrushing Strength (%): 30 LOI M/m (%): <1.5
Highlight:

5A Molecular Sieve In Psa

,

Psa Equipment Molecular Sieve

,

Oxygen Zeolite Zsm5 Catalyst

5A Molecular Sieve In Psa Equipment Molecular Sieve For Oxygen Concentrator Oxygen Zeolite Zsm5 Catalyst5A Molecular Sieve In Psa Equipment Molecular Sieve For Oxygen Zeolite Zsm5 Catalyst 0
Product Parameters
5A Molecular Sieve In Psa Equipment Molecular Sieve For Oxygen Zeolite Zsm5 Catalyst 1
It is a high performance lithium exchanged low silica form of the X-type zeolite with exceptional nitrogen capacity to provide optimal performance in the separation of oxygen fromair in medical oxygen concentrators. It is developed and designed for the production of up to 95% oxygen rich air streams in medical oxygen concentrators with air flows up to 10 liters per minute.There are three mechanisms of adsorption separation: steric hindrance effect, kinetic effect and equilibrium effect.


Technical Parameter:
Item
Unit
Sphere(granular)
Shape
/
NKXPSA
Diameter
mm
θ1.2~1.8
θ1.6~2.36
Bulk Density
kg/L
0.62~0.68
0.62~0.68
Crushing strength
N/Pellet
≥10
≥15
Abrasion ratio
%wt
≤0.3
Static N2 absorption
ml/g
≥22.0
N2 /O2 separation coefficient
/
≥4.1
Static water absorption
%wt
≥28.0
Water content
%wt
≤1.0
Absorption pressure for oxygen production
KP
50
Desorption pressure
KP
-50
Outlet oxygen concentration
%
93
Oxygen production capacity
/ton Molecular sieve
45m3/per ton Molecular Sieve ≤1.0

Application
steel, nonferrous metallurgy, chemical industry, furnaces energy saving, environmental protection, paper making, aquaculture, health care.

Characteristics
Lithium based molecular sieve is a synthetic zeolite of lithium-type crystal structure, large Nitrogen adsorption capacity, high efficiency of oxygen/nitrogen separation.
In addition to ethanol, a well-designed and manufactured sieve is not only used to dehydrate the ethanol hydrated vapors, but is highly useful for dehydrating other types of chemicals too. Thus, gives a facility to use this system in future operations as well.
It shows high N2/O2 separation under a very low pressure, which lowers the consumption of producing oxygen.
The advantage of on the equilibrium adsorption capacity, It applies to various VPSA device for producing oxygen.
