Desiccant Molecular Sieve 3A 4A Ethanol Drying Agent Air Filter Desiccant Dryer

Desiccant Molecular Sieve 3A 4A Ethanol Drying Agent Air Filter Desiccant Dryer
Desiccant Molecular Sieve 3A 4A Ethanol Drying Agent Air Filter Desiccant Dryer
Desiccant Molecular Sieve 3A 4A Ethanol Drying Agent Air Filter Desiccant Dryer Desiccant Molecular Sieve 3A 4A Ethanol Drying Agent Air Filter Desiccant Dryer Desiccant Molecular Sieve 3A 4A Ethanol Drying Agent Air Filter Desiccant Dryer Desiccant Molecular Sieve 3A 4A Ethanol Drying Agent Air Filter Desiccant Dryer
Basic Information
Place of Origin: China
Brand Name: Naike
Certification: 63231-69-6
Model Number: Oxygen Molecular Sieve
Minimum Order Quantity: 1 kilograms(Min. order)
Price: $50.00 - $500.00/ kilogram/ kilogram |1 kilogram
Packaging Details: Conventional packing
Delivery Time: 5-8 work day
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram, L/C, D/A
Supply Ability: 5000 Tons per Month
Contact Now
Features: Oxygen Concentrator Classification: Chemical Auxiliary Agent
MF: Na2O. Al2O3. (2.8±0.2) SiO2. (6~7)H2O Purity: >92%
Type: Adsorbent Usage: Paper Chemicals, Petroleum Additives, Plastic Auxiliary Agents, Water Treatment Chemicals
Product: Molecular Sieve For Oxygen Concentrator Static Water Adsorption (%): ≥27
Static CO2 Adsorption (%): ≥18.5 Bulk Density (g/ml): 0.65-0.70
Bulk Density(g/cm3): ≥0.62 Scrushing Strength (%): 30
LOI M/m (%): <1.5
Highlight:

Desiccant Molecular Sieve 3A

,

Sieve 3A Ethanol Drying Agent

,

Sieve 4A Ethanol Drying Agent

Desiccant Molecular Sieve 3A 4A Ethanol Drying Agent Air Filter Desiccant Dryer nature gas dryerDesiccant Molecular Sieve 3A 4A Ethanol Drying Agent Air Filter Desiccant Dryer 0
Product Parameters
Desiccant Molecular Sieve 3A 4A Ethanol Drying Agent Air Filter Desiccant Dryer 1
zeolite 4a molecular sieve is also called zeolite 4a, 4a molecular sieve. 4a is a type of zeolite molecular sieve, we also have type 3a, 5a, 10a, 13x. All are Chemical Auxiliary Agent.
product name
Zeolite 3a molecular sieve, zeolite 3a, 3a molecular sieve
Type
3a
Brand
Naike
Shape
Pellet,sphere
Size
1.6-2.5mm,3-5mm
Material
Alkali alumino-silicate
Color
As picture
Package
Carton box, iron drum
MOQ
1 TON
Regenetion
Yes
Delivery
7-15 days
Place of origin
Jiangxi, China
Price
FOB shenzhen
Payment term
T/T, L/C, west union
Application
Natural gas drying, remove CO2, packaging desiccant
Introduction
Zeolite molecular sieve 3A is an alkali metal alumino silicate; it is the potassium form of the Type A crystal structure. Type 3A
has an effective pore opening of 3 angstroms (0.3 nm). It is large enough to allow in moisure, but excludes moleculars such as
unsatureated hydrocarbons which can potentially form polymers: and this maximises lifetime when dehydrating such molecules.

Typical Chemical Formula
0.45k2O ·0.55Na2O·Al2O3 ·2.SiO2· 4.5H2O

Application
1) Drying and removing of CO2 from natural gas, LPG, air, inert and athmospheric gases, etc.
2) Removal of hydrocarbons, ammonia and methanol from gas streams (ammonia syn gas treating)
3) Special types are used in the air break units of buses, trucks and locomotives.
4) Packed in small bags, it may be used simply as a packaging desiccant.

Technical Parameter
Item
unit
target
Shape

pellet
ball
Diameter
mm
1.5-1.7
3.0-3.3
1.7-2.5
3.0-5.0
Size ratio up to grade
%
≥98
≥98
≥96
≥96
Bulk density
g/ml
≥0.64
≥0.64
≥0.68
≥0.68
Abrasion rate
%
≤0.20
≤0.25
≤0.1
≤0.1
Crushing strength
N/p
≥45
≥60
≥30
≥70
Water adsorption
%
≥20
≥20
≥20
≥20
Packing water
%
≥15
≥15
≥15
≥15



Packing:
By carton box, each box 30kg or 25kg, inside airtight bag.
Or 40kg/sealed iron drum, inside airtight bag.

Regeneration:
Molecular sieve Type 3A can be regenerated by either heating in the case of thermal swing processes; or by lowering the pressure
in the case of pressure swing processes.To remove moisture from a 3A molecular sieve, a temperature of 200-230°C is required. A
properly regenerated molecular sieve can give moisture dew points below -100°C.The outlet concentrations on a pressure swing
process will depend on the gas present, and on the conditions of the process

Size:
3A - Zeolites are available in beads of 1-2 mm, (10x18 mesh) 2-3 mm, (8x12 mesh) , 2.5-5 mm, (4x8 mesh) and as powder, and in
pellet 1.6, 3.2.
NAIKE Molecular Sieves are normally used in the process of drying gases and liquids.Molecular Sieves are a crystalline composition with uniform pores that is measured in angstroms.
This composition makes Molecular Sieve more effective than other types of desiccants.

Molecular Sieve Desiccants are extremely effective at removing water from liquids and gases. They are even more effective silica gel or activated alumina, because of their crystalline composition; they can create virtually water-free products. These sieves are veryuseful in cryogenic operations where liquefaction of gases is required and water must be eliminated to avoid freezing.

Molecular sieves offer a variety of adsorption selectivity based on molecular size. molecular affinity for the sieve crystal surface, and shape of the molecule. Using this type of system is exceptionally uncomplicated for diminishing impurities to practically indiscernible levels compared to other liquid separation systems. The ease of use and superior efficiency when compared to other adsorptionsystems makes the most popular engineering solution a molecular sieve system.

Molecular sieves are used for drying gas streams with in the petroleum industry; used todry solvent within a laboratory along with a extensive range of catalytic applications. Additionally, Molecular Sieves are used in a great many air filtration and liquid filtration scenarios.

Type of molecular sieve:3A,4A,5A,13X,Carbon
Package:Carton box;Carton drum;Steel drum;Jumbo bag
Details Images
Desiccant Molecular Sieve 3A 4A Ethanol Drying Agent Air Filter Desiccant Dryer 2
Desiccant Molecular Sieve 3A 4A Ethanol Drying Agent Air Filter Desiccant Dryer 3
Desiccant Molecular Sieve 3A 4A Ethanol Drying Agent Air Filter Desiccant Dryer 4
Desiccant Molecular Sieve 3A 4A Ethanol Drying Agent Air Filter Desiccant Dryer 5
Desiccant Molecular Sieve 3A 4A Ethanol Drying Agent Air Filter Desiccant Dryer 6
Desiccant Molecular Sieve 3A 4A Ethanol Drying Agent Air Filter Desiccant Dryer 7
Recommend Products
Desiccant Molecular Sieve 3A 4A Ethanol Drying Agent Air Filter Desiccant Dryer 8
Company Profile
Desiccant Molecular Sieve 3A 4A Ethanol Drying Agent Air Filter Desiccant Dryer 9
Desiccant Molecular Sieve 3A 4A Ethanol Drying Agent Air Filter Desiccant Dryer 10
Exhibition
Desiccant Molecular Sieve 3A 4A Ethanol Drying Agent Air Filter Desiccant Dryer 11
Cooperation Case
Desiccant Molecular Sieve 3A 4A Ethanol Drying Agent Air Filter Desiccant Dryer 12
Desiccant Molecular Sieve 3A 4A Ethanol Drying Agent Air Filter Desiccant Dryer 13
Desiccant Molecular Sieve 3A 4A Ethanol Drying Agent Air Filter Desiccant Dryer 14
FAQ
Q1.Q:What are your main products?
A:Our main products are molecular sieve, ceramic ball, plastic,ceramic and metal tower packing, column internal parts, MBBR, etc...

Q2:Why to choose us?
A:Naike Chemical established since 1973. * Factory direct selling * High quality control * Promopt delivery and competitive price

Q3:What is the MOQ?
A:Our MOQ is 1 cubic meter or 1 ton. The price will be a little higher is the quantity is less tan 1 cubic meter or 1 ton.

Q4:What is the delivery time?
A:It will takes about 3-5 days. But the exact time is according to actual situation.

Q5:How do I pay for my purchase order?
A:T/T, L/C at sight, paypal, Alibaba Trade Assurance, etc...

Q6:Can I have my own customized product?
A:Yes, your customized requirements are welcome.
