Insulating Glass Molecular Sieve Desiccant Drying Catalyst Molecular Sieve

Insulating Glass Molecular Sieve Desiccant Drying Catalyst Molecular Sieve
Insulating Glass Molecular Sieve Desiccant Drying Catalyst Molecular Sieve Insulating Glass Molecular Sieve Desiccant Drying Catalyst Molecular Sieve Insulating Glass Molecular Sieve Desiccant Drying Catalyst Molecular Sieve Insulating Glass Molecular Sieve Desiccant Drying Catalyst Molecular Sieve Insulating Glass Molecular Sieve Desiccant Drying Catalyst Molecular Sieve
Basic Information
Place of Origin: CHINA JIANGXI
Brand Name: NKCHEM
Certification: ISO9001:2000 & MSDS
Model Number: 63231-69-6
Minimum Order Quantity: 1 kilograms(Min. order)
Price: $50.00 - $500.00/ kilogram |1 kilogram/
Packaging Details: Conventional packing
Delivery Time: 5-8work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram, L/C, D/A
Supply Ability: 1 - 1000+kilograms+PER DAY
Contact Now
Classification: Chemical Auxiliary Agent MF: Na2O. Al2O3. (2.8±0.2) SiO2. (6~7)H2O
Other Names: Molecular Sieve Oxygen Purity: >92%
Type: Adsorbent Adsorbent Variety: Molecular Sieve
Usage: Paper Chemicals, Petroleum Additives, Plastic Auxiliary Agents, Water Treatment Chemicals Product: Molecular Sieve For Oxygen Concentrator
Static Water Adsorption (%): ≥27 Static CO2 Adsorption (%): ≥18.5
Bulk Density (g/ml): 0.65-0.70 Bulk Density(g/cm3): ≥0.62
Scrushing Strength (%): 30 LOI M/m (%): <1.5
Highlight:

Insulating Glass Molecular Sieve

,

Desiccant Drying Catalyst Molecular Sieve

,

Catalyst Molecular Sieve

Insulating Glass Molecular Sieve Desiccant Drying Catalyst Molecular Sieve Oxygen Catalyst For Oil IndustryInsulating Glass Molecular Sieve Desiccant Drying Catalyst Molecular Sieve 0
Product Parameters
Insulating Glass Molecular Sieve Desiccant Drying Catalyst Molecular Sieve 1
It is a high performance lithium exchanged low silica form of the X-type zeolite with exceptional nitrogen capacity to provide optimal performance in the separation of oxygen fromair in medical oxygen concentrators. It is developed and designed for the production of up to 95% oxygen rich air streams in medical oxygen concentrators with air flows up to 10 liters per minute.There are three mechanisms of adsorption separation: steric hindrance effect, kinetic effect and equilibrium effect.


Technical Parameter:
Item
Unit
Sphere(granular)
Shape
/
NKXPSA
Diameter
mm
θ1.2~1.8
θ1.6~2.36
Bulk Density
kg/L
0.62~0.68
0.62~0.68
Crushing strength
N/Pellet
≥10
≥15
Abrasion ratio
%wt
≤0.3
Static N2 absorption
ml/g
≥22.0
N2 /O2 separation coefficient
/
≥4.1
Static water absorption
%wt
≥28.0
Water content
%wt
≤1.0
Absorption pressure for oxygen production
KP
50
Desorption pressure
KP
-50
Outlet oxygen concentration
%
93
Oxygen production capacity
/ton Molecular sieve
45m3/per ton Molecular Sieve ≤1.0


Application
steel, nonferrous metallurgy, chemical industry, furnaces energy saving, environmental protection, paper making, aquaculture, health care.

Characteristics
Lithium based molecular sieve is a synthetic zeolite of lithium-type crystal structure, large Nitrogen adsorption capacity, high efficiency of oxygen/nitrogen separation.
In addition to ethanol, a well-designed and manufactured sieve is not only used to dehydrate the ethanol hydrated vapors, but is highly useful for dehydrating other types of chemicals too. Thus, gives a facility to use this system in future operations as well.
It shows high N2/O2 separation under a very low pressure, which lowers the consumption of producing oxygen.
The advantage of on the equilibrium adsorption capacity, It applies to various VPSA device for producing oxygen.



Details Images
Insulating Glass Molecular Sieve Desiccant Drying Catalyst Molecular Sieve 2
Insulating Glass Molecular Sieve Desiccant Drying Catalyst Molecular Sieve 3
Insulating Glass Molecular Sieve Desiccant Drying Catalyst Molecular Sieve 4
Insulating Glass Molecular Sieve Desiccant Drying Catalyst Molecular Sieve 5
Insulating Glass Molecular Sieve Desiccant Drying Catalyst Molecular Sieve 6
Insulating Glass Molecular Sieve Desiccant Drying Catalyst Molecular Sieve 7
